SG MOLD High Precision Non-Standard Mold Base

Stable foundation structure for precision injection and die casting molds

SG MOLD's non-standard mold base is
For the manufacture of plastic injection mold and die casting mold
It is a high-precision mold basic structure designed and processed based on actual production conditions.

It's not just a frame that meets the standard,
Comprehensive consideration of product shape, cavity composition, injection conditions, and mold life
It provides an optimized structure for each project.

Product Overview

Product Type: Non-Standard Mold Base

Applicable field: injection mold / die casting mold

Fabrication Method: Drawings-Based 1:1 Customization

Processing method: CNC precision processing + full inspection

SG MOLD mold base is
It is designed with core criteria such as alignment accuracy, structural rigidity, and repetitive production stability of the mold.

structural features
1. Optimization of fixed/movement-side structures

Design A-Plate and B-Plate separately

Clearly distinguish between the forming block (Core/Cavity) and the structural plate

Structural design to minimize deformation even during prolonged repeated injection

This effectively prevents misalignment, flagging, and injection instability when assembling a mold.

2. High-stiff frame design

Use of high-quality steel

Thickness and rib structure are designed based on actual load conditions

Maintaining stable structures even in large and medium molds

The mold base is not just a support structure
It's a key factor that's directly related to the entire life of the mold
SG MOLD considers structural rigidity as its top priority.

3. Cooling and internal processing response

Cooling circuit machinable (straight line/composite line)

Water line, baffle structure drawing can be reflected

Positional design considering actual molding conditions

The cooling structure is designed as a key element of injection cycle and quality stability, not a simple machining option.

4. Ejector System Response Structure

Ejector Plate, Retainer Plate Mounting Structure

Space design for pin arrangement, stroke and load conditions

Maintain stable operation in case of repeated demolding

B plate and substructure are
It is directly related to demold stability, so processing precision is strictly controlled.

Processing precision and quality control

Average machining tolerance: ±0.01 mm

High precision requirements: Up to ±0.005mm capable

3D Instrument (CMM) based full inspection

Provide physical photos and inspection data before shipment

SG MOLD is not a "processor."
It is a manufacturer specializing in mold base that understands and manufactures mold structure.

application case

automobile parts injection mold

Home appliances and household goods injection mold

industrial plastic parts

High Stiffness Requirement Non-Standard Mold Structure

From small molds to large mold bases
Apply the same quality standards regardless of project size.

The difference between SG MOLD mold base

Non-standard structure professional design experience

own processing plant

Quick production response

a reasonable cost structure

Korean market response experience and communication support

Consultation and production inquiries

Non-standard mold bases are
Quality cannot be judged only by standard standards.

From the drawing stage
It is important to review the structure, processability, and assembly stability together.

SG MOLD responds directly from drawing-based technical consultation to production.
If you need a mold base suitable for the project, please feel free to contact us.
